Send InquiryHeating And Pumping Unit
Heating And Pumping Unit Specification
- Max Suction
- 8 m
- Features
- Corrosion Resistance, High Temperature Stability, Leak-proof Operation
- Speed
- 2900 rpm
- Mounting Type
- Floor Mounted
- Discharge Pressure
- Up to 0.6 Mpa
- Control System
- Automatic Control Panel
- Noise Level
- 75 dB
- Frequency
- 50 Hz / 60 Hz
- Theory
- Centrifugal Pump
- Caliber
- 25 mm
- Inlet/Outlet
- DN25/DN25
- Head Size
- 15 m 50 m
- Flow Rate
- 2 m/h 10 m/h
- Voltage
- 380 V / 220 V
- Working Temperature
- Up to 320C
- Material
- Stainless Steel / Carbon Steel
- Structure
- Skid Mounted Unit
- Power
- 1.5 kW 7.5 kW
- Standard
- ISO 9001 Certified
- Fuel Type
- Electric Driven
- Pressure
- 0.6 Mpa
- Usage
- Industrial Heating, Oil Transfer
- Application
- Heating and Pumping
- Suction Type
- Horizontal Suction
- Seals Type
- Mechanical Seal
- Priming
- Self Priming
- Pump Type
- Hot Oil Circulation Pump
- Capacity
- 2 10 m/h
- Weight
- Approx. 250 kg
- Color
- Industrial Blue or Custom
- Safety
- Overheat Protection, Emergency Stop
- Connections
- Threaded or Flanged
- Heating Medium
- Thermal Oil
- Pump Life
- Long Service Life
- Ambient Temperature
- Up to 45°C
- Insulation Type
- High-Temperature Thermal Insulation
- Installation
- Compact Modular Design
Heating And Pumping Unit Trade Information
- Minimum Order Quantity
- 2 Units
- FOB Port
- TKD
- Supply Ability
- 2 Units Per Week
- Delivery Time
- 1 Week
- Main Export Market(s)
- Middle East, Africa, Asia
- Main Domestic Market
- All India
About Heating And Pumping Unit
Heating And Pumping Unit
To supply adequate Quantity of Oil to the burners at specific temperature and pressure, 1 No. oil heating & pumping FTS unit model Duplex comprising of oil pumps coupled with motor Crompton/ABB make with standard accessories like Pressure Gauges, Temperature Gauge, and inter connecting piping along with gate valve etc will be supplied with the furnace. The whole unit shall be mounted on a steel fabricated trey.
To adequately supply the oil to the burners and similar equipment at a certain pressure and temperature, our company is providing preferred Heating and Pumping Unit. It is available in Duplex model that has integrated oil pumps equipped with Compton or ABB motor. This unit is designed with standard accessories, for example, inter connecting pipes, temperature gauge, Pressure Gauges, gate valve and much more. Besides, the provided Heating and Pumping Unit can be easily equipped with the furnace. Our unit can be effortlessly installed on a fabricated steel tray.
Advanced Thermal Insulation Technology
The unit is fitted with high-temperature thermal insulation for enhanced safety and efficiency during continuous industrial operations. Insulation minimizes energy loss and ensures stable system performance even under elevated working conditions up to 320C, while also safeguarding personnel and equipment against accidental exposure.
Modular Compact Design for Easy Installation
With its compact, modular construction, this heating and pumping unit is conveniently floor-mounted and skid-mounted for rapid setup in industrial facilities. The streamlined design reduces installation time, adapts to various workspace layouts, and permits straightforward integration with existing piping systems through threaded or flanged connections.
Robust Safety and Control Features
Equipped with multiple safety protocols, including overheat protection and an emergency stop mechanism, this unit ensures secure operation. The automatic control panel provides precise management of heating and pumping activities, while leak-proof mechanical seals maintain system integrity, minimizing operational risks.
FAQs of Heating And Pumping Unit:
Q: How is the Heating and Pumping Unit installed at an industrial site?
A: The unit features a compact, modular skid-mounted design allowing for simple floor-mounted installation. It connects easily to existing systems using threaded or flanged inlet and outlet connections (DN25), requiring minimal space and setup time.Q: What heating medium does the unit utilize, and what temperature range can it handle?
A: The unit uses thermal oil as the heating medium. It is built to operate efficiently at working temperatures up to 320C, thanks to high-temperature thermal insulation and corrosion-resistant materials.Q: When should the emergency stop or overheat protection features be activated?
A: The emergency stop should be used immediately in case of system failure or unsafe operating conditions. Overheat protection is automatically engaged if temperatures exceed designated safety thresholds, preventing damage and ensuring operator safety.Q: Where can this heating and pumping unit be applied?
A: This industrial unit is suitable for various sectors including chemical processing, oil transfer, and heating systemswhere high temperature stability, long-term reliability, and safe operation are required, especially in environments up to 45C ambient temperature.Q: What is the process for maintaining pump longevity and leak-proof operation?
A: Regular inspection of mechanical seals, thermal insulation, and the automatic control system ensures long service life and prevents leaks. Adherence to the units ISO 9001-certified maintenance guidelines is recommended for optimal performance.Q: How does the unit ensure reliable oil transfer and heating?
A: With a centrifugal self-priming pump, horizontal suction style, and robust structure, it delivers consistent flow rates between 210 m/h and discharge pressures up to 0.6 Mpa, making it ideal for continuous industrial heating and oil transfer.Q: What are the benefits of the corrosion-resistant and high-temperature stable design?
A: Constructed from stainless steel or carbon steel, and coated in industrial blue or custom colors, the unit resists corrosion and maintains performance in harsh conditions. This ensures operational continuity, reduces maintenance needs, and increases system service life.Tell us about your requirement
